CAKIRYILDIZ
Yacht for Sale
Length:
134′ 5″ / 41.00m
| Builder: East Yachting
| Year: 2013
CAKIRYILDIZ Yacht for Sale - 134 East Yachting
Contact Us For More Information
Detailed Information
MAIN CHARACTERISTICS
GENERAL
Built by East Shipyard-Bodrum
Year 2013
Length 41.00 mt (incl. bow sprit)
Beam 8.90 mt
Draft 3.98 mt
Classification BV Hull Mach, Charter Yacht, W, Unrestricted Navigation
Flag Turkey
GRT 228
Displacement 250.000 kg
Designer Akivades Design&Consultancy
Naval Architect Akivades Design&Consultancy
Interior Designer East Shipyard
CONSTRUCTION
► Wood
► Laminated mahogany 9 ply,
► Keel, frames and stringers laminated mahogany,
► Screws, nails and bolts silicone bronze,
► Staples, composite,
► Epoxy: International Epiglass
► Paint: topsides are fully Epifanes varnish, underwater International antifouling system
► Decking: 8 ply with insulation plus 15 mm Burma teak
► Interior: fully Burma teak
► Custom made stainless steel portholes, hatches and watertight doors
CAPACITIES
Speed 14.5 kn
Fuel capacity 9,500 lt
Water capacity 5,500 lt
Black water capacity 6,360 lt
Grey water capacity included in black water
MACHINERY
Engines 2x CATERPILLAR
Engine model 2x CAT C18 ACERT, 600 HP, 1800 rpm, B Rating
Engine hours 2000 hrs
Fuel Diesel
Propulsion Conventional type (with g/b, shaft, a bracket and fixed pitch props)
Gearboxes 2x ZF W650, Ratio 3,605:1, with live PTO
Steering Hydromarine Steering Gear
Stabilizers N/A
GENERATORS
Generators 2x CAT 4.4 DITA 69 kWe 50 Hz plus CAT 4.4. DINA 38 kWe 50 Hz
Generator hours 8000 hours on 69kW
ELECTRICITY
► 380 VAC main switchboard and 24 VDC&230 VAC main switchboard has been located in Engine room
► 20 pcs independent switchboard panels,
► All generators could be running in parallel conditions, both automatically or manually
► Inverter: 2x Victron Energy Multiplus 5000 W
► Battery Chargers: Victron Energy Skylla and Orion models,
► Batteries: Victron Energy 12x 2 V-1500 A Gel type batteries,
AGM type batteries for starting and emergency, Shore power Batteries
► Victron Energy 12x 2 V-1500 A Gel type batteries, AGM type batteries for starting and emergency
AIR CONDITIONING
► Marincold Air Handling Unit : MC320 H/C – 320.000 BTU
► Marincold Fancoils for each cabin and compartment
OTHER MACHINERY
Bow Thruster Wesmar hydraulic fixed pitch propeller
Stern Thruster N/A
Water makers 2x SELMAR PACIFIC 280 CS, 600 lt/hrs
Propellers 2x Fixed Pitch Al Cu3 Bronze propeller
Shafts 2x stainless Steel Shafts Rudder angle indicators Hydromarine Rudder Angle İndicator
Fuel filters 2x Separ SWK-2000/5
Fuel Filter for each main engine
Fuel oil separator N/A
Oil/water separator N/A
Fire bilge pump 2 pcs G&R ACM 501 BT (15 cbm/hr cap) bilge&fire pump 1 pc G&R Diesel Driven
Emergency fire pump
Boilers 2x 100 lt G&R Boilers (with independent circulation pump)
Sewage treatment 2x HAMANN Super Mini Plus
Waste water treatment unit
WC’s EVAC Vacuum System, 24 VDC and 230 VAC usable Fresh Air
Make up unit Marincold Fresh Air Make Up Unit: MCF/A 480 – 48.000 BTU
ACCOMMODATION
OWNER Master Cabin located aft side of yacht
GUESTS 4x Guest cabin
STAFF Hostes cabin
CREW Captain Cabin and crew cabins
(fore side)
GALLEY & LAUNDRY EQUIPMENT
► Electric powered cooking plate with 5 sections,
► Franke owen
► 2 pcs Siemens Refrigerator
► 2 pcs Deepfreeze
► 1 pc washşng machine,
► 1 pc drying machine
DECK EQUIPMENT
Steering System Hydromarine Hydraulic System
Windlass 2x Hydromarine Hydraulic Windlass
Anchors 2x 230kg HHP Stockless Anchors
Chains 19mm Galvanized Chain, 275mt
COMMUNICATIONS, NAVIGATION & ENTERTAINMENT EQUIPMENT
COMMUNICATIONS EQUIPMENT
► Raymarine VHF & UHF
NAVIGATION EQUIPMENT
► 2x Raymarine Radar,
► Raymarine Autopilot,
► Raymarine Chart Plotter,
► Raymarine Echosunder & Sppedlog
ENTERTAINMENT EQUIPMENT
► Satellite TV in each cabin and saloon
► Home cinema in saloon and master cabin
► Sonos central music system available in every cabins and
areas
TENDERS & WATERSPORTS EQUIPMENT
TENDERS
► Zodiac Medline 5,40 mt with 100 HP Yamaha outboard
► Zodiac Cadet 3,10 mt with 20 HP Yamaha Outboard
WATERSPORTS EQUIPMENT
► Banana (3 person)
► 2 sets water ski set for adults
► 1 set water ski set for children
► Kneeboard
► wakeboard
► 2x Ringo
► 2x kano
SAFETY & SECURITY EQUIPMENT
► 2x Liferaft (12 person/each)
► 12x Lifejacket
► 5x Lifejacket (for children)
► 6x Lifebuoy
► Line Throwing Set
► 12x parachute Signal Rockets
► 2x Handheld Radiotelephone Apparatus
► Fixed CO2 system with Engine Room (acc to BV Rules)
► Fire dedection System for each compartment
► 14x Powder Extinguisher ( 6 kg)
► 10x Powder Extinguisher (2 kg)
► Quick Closing Valve System (for fuel tanks)
► Fire Station
► Quick Clos Dampers for Engine Room fans
► Fire Hoses and Nozzles for each fire hydrant
SAIL & RIGGING
Main Sail 227 m2
Mizzen Sail 193 m2
Spinnaker Sail 95 m2
Genova Sail 233 m2
► Laminated wooden masts
► Sail winches: 10 pcs Andersen stainless steel hydraulic winches on deck
► Furlings, boom vangs and backstays: Bamar
► Deck blocks and sailing equipments: Antal
► Custom made stainless steel liftings and accessories
EXCLUSIONS
A complete list of exclusions is available upon request.
